Wholesale Vertical Electrophoresis System DYCZ-22A

Short Description:

DYCZ-22A is a single slab vertical electrophoresis cell used for separating, purifying and preparing protein charged particles. It is a single plate structure product. This vertical electrophoresis tank is very economical and easy to use.


  • Gel Size (L×W): 170×170mm
  • Comb: 20 wells and 26 wells
  • Comb Thickness: 1.0mm and 1.5mm
  • Number of Samples: 40-52
  • Buffer Volume: 600 ml
  • Product Detail

    Product Tags

    Specification

    Dimension (L×W×H)

    240×150×240mm

    Gel Size (L×W)

    170×170mm

    Comb

    20 wells and 26 wells

    Comb Thickness

    1.0mm and 1.5mm

    Number of Samples

    40-52

    Buffer Volume

    600 ml

    Weight

    6.0kg

    Application

    DYCZ-22A electrophoresis cell is used for separating, purifying and preparing protein charged particles in biochemical analysis and research. It is widely suitable for variety of gel electrophoresis, such as polyacrylamide gel, starch gel.

    csdc

    Description

    DYCZ-22A can be used for SDS-PAGE, Native PAGE electrophoresis experiment. It is delicate and simple, but very economical and easy to use. It  is a single slab gel system which can cast gel size 170×170mm. It saves buffer solution, and the buffer volume is about 600ml. It is really a good choice for small quantity of experiment samples.

    Featured

    • The main tank body is made of high quality transparent polycarbonate, exquisite and durable, easy for observation;

    • The Main tank body is equipped pure platinum electrodes with high conductibility;

    • Easy and convenient to load samples;

    • Two ways available to seal the gel room to cast gel;

    • Equipped a unit for placing ice for cooling;

    Upper and lower tank structure, save buffer solution;

    20 wells and 26 wells combs with the teeth thickness of 1.0mm and 1.5mm;

    Four clamps help to clamp glass plates with main tank body;

    • Clear band and stable performance.
